ASUS FA506NCR-HN008W

Marketing Name
ASUS TUF Gaming A15

Operating System
Windows 11 Home

Office
1-month trial for new Microsoft 365 customers. Credit card required.

Color
Graphite Black

Dimension (W x D x H)
35.9 x 25.6 x 2.28 ~ 2.45 cm (14.13" x 10.08" x 0.90" ~ 0.96")

Weight
2.30 Kg (5.07 lbs)

Processor
AMD Ryzen™ 7 7435HS Mobile Processor 3.1GHz (20MB Cache, up to 4.5 GHz, 8 cores, 16 Threads)

Chipset
TBD

Intergrated GPU
AMD Radeon™ Graphics

Discrete/Optimus
Discrete

Graphic
NVIDIA® GeForce RTX™ 3050 Laptop GPU

Graphic Wattage
Up to 1675MHz at 60W (75W with Dynamic Boost)

Graphic Memory
4GB GDDR6

Panel Size
15.6-inch

Resolution
FHD (1920 x 1080) 16:9

Refresh Rate
144Hz

Viewing Angle
85/85/85/85

Panel Tech
Value IPS-level

Brightness
250nits

Contrast Ratio
1000:1

NTSC %
45%

SRGB %
62.5%

Adobe %
47.34%

DCI-P3 %
N/A

Glare
Anti-glare display

Adaptive-Sync technology
Adaptive-Sync

Pantone
N/A

Support Dolby Vision HDR
N/A

On board memory
N/A

DIMM Memory
16GB DDR5-4800 SO-DIMM

Total System Memory
DDR5 16GB

Memory Slot
2x SO-DIMM slots

Memory Max.
32GB

Storage
512GB PCIe® 4.0 NVMe™ M.2 SSD

M.2 slots support either SATA or NVMe
2

M.2 SSD Support List
M.2 512GB G4x4 PCIe SSD
M.2 1TB G4x4 PCIe SSD

Expansion Slot (includes used)
2x DDR5 SO-DIMM slots

2x M.2 PCIe

LAN
10/100/1000 Mbps

Wireless
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.)

I/O Ports
1x RJ45 LAN port

1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ (data speed up to 10Gbps)

3x USB 3.2 Gen 1 Type-A (data speed up to 5Gbps)

Display output
1x HDMI 2.1 TMDS

Camera
720P HD camera

Mic
Built-in array microphone

Keyboard Type
Backlit Chiclet Keyboard 1-Zone RGB

Aura Sync
N/A

Touchpad
Touchpad


Speakers
2-speaker system

Audio
1x 3.5mm Combo Audio Jack

Built-in array microphone

Audio Tech
AI noise-canceling technology

DTS software

Hi-Res certification (for headphone)

Security
BIOS Administrator Password and User Password Protection

Kensington Security Slot™

Trusted Platform Module (Firmware TPM)

Antivirus
McAfee® 30 days free trial

Battery
48WHrs, 3S1P, 3-cell Li-ion

Fast charging
Recharge from 0-50% in 30 minutes

Power
o6.0, 180W AC Adapter, Output: 20V DC, 9A, 180W, Input: 100~240V AC, 50/60Hz universal

Xbox Game Pass
Xbox Game Pass Ultimate_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Ultimate. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)

Ecolabels & Compliances
N/A
