Supermicro MB 1xLGA1151, iC232,DDR4,6xSATA3,PCIe 3.0 (1 x8, 1 x8 (in x16), 1 x4 (in x8)), IPMI

Serverový konfigurátor

SUPERMICRO MB 1xLGA1151, iC232,DDR4,6xSATA3,PCIe 3.0 (1 x8, 1 x8 (in x16), 1 x4 (in x8)), IPMI CPU/Chipset • Intel Skylake Xeon E3-1200 v5 and 6th Gen Core i3, Pentium, Celeron processors. Skt-H4, LGA1151 • Intel C232 PCH • 4x ECC/non-ECC UDIMM slots, up to 64GB DDR4-2133MHz • 3 PCIe 3.0 slots: 1 x8, 1 x8 (in x16), 1 x4 (in x8) • Slots 7 support NVMe SSD via PCIe AOC • 6x SATA 6Gb/s (RAID 0, 1, 10, 5) I/O Connectors • 1 VGA D-Sub Connector, 1x COM Port (rear) • Dual GbE LAN ports (2x i210) • 5x USB 3.0 (2 rear, 1 Type-A, 2 header) • 6x USB 2.0 (2 rear, 4 via header) • 2x Super-DOM connectors (yellow color). Misc • TPM header, IPMI 2.0 w/ Aspeed on Dedicated LAN (-F only) • 0 ~ 50 Degree C Operating Temperature. • PCB. 9.6” x 9.6” uATX, FCC B, WHQL. Optimized Chassis & RSC • SC510/512, SC813M, SC731, SC113MTQ, RSC-RR1U-E16, RSC-RR1U-E8 Major Applications • Most cost efficient entry-level server board Key Features 1. Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200 v5, Intel® 6th Gen. Core™ i3 series, Intel® Celeron® and Intel® Pentium® 2. Intel® C232 chipset 3. Up to 64GB Unbuffered ECC UDIMM DDR4 2133MHz; 4x DIMM slots 4. Expansion slots: 1 PCI-E 3.0 x8 (in x16), 1 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8) 5. Dual GbE LAN with Intel® i210-AT 6. 6x SATA3 (6Gbps) via C232; RAID 0, 1, 5, 10 7. I/O: 1x VGA, 1x COM, 2x SuperDOM 8. 2x SuperDOM with built-in power 9. 5x USB 3.0 (2 rear + 2 via header + 1 Type A), 6x USB 2.0 (2 rear + 4 via headers) 10. Integrated IPMI 2.0 and KVM with Dedicated LAN Physical Stats Form Factor microATX Dimensions 9.6" x 9.6", (24.4cm x 24.4cm) Processor/Cache CPU Single Socket H4 (LGA 1151) supports: Intel® Xeon® processor E3-1200 v5, Intel® 6th Gen Core™ i3, Intel® Pentium®, Intel® Celeron® processors CPU TDP up to 80W System Memory Memory Capacity 4x 288-pin DDR4 DIMM slots Up to 64GB DDR4 ECC UDIMM Memory Type 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (UDIMM) gold-plated DIMMs DIMM Sizes 16GB, 8GB, 4GB Memory Voltage 1.2 V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset Intel® C232 chipset SATA SATA3 (6Gbps) via C232 controller RAID 0, 1, 5, 10 support IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC Network Controllers Dual Intel® I210-AT Gigabit Ethernet LAN ports Virtual Machine Device Queues reduce I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output Graphics ASPEED AST2400 BMC Input / Output SATA 6x SATA3 (6Gbps) ports LAN 2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port USB 5x USB 3.0 ports (2 rear + 2 via header + 1 Type A) 6x USB 2.0 ports (2 rear + 4 via headers) Video 1x VGA port Serial Port / Header 1x COM port (1 rear) SuperDOM 2x SuperDOM (Disk on Module) ports with built-in power TPM 1x TPM 1.2 20-pin Header Chassis (Optimized for X11SSL-F ) 1U Chassis: SC813MFTQC-505CB SC813MFTQ-R400CB SC813MTQ-350CB SC512L-200B SC512F-350B SC811TQ-441B SC113MFAC2-341CB SC113MFAC2-R606CB SC510-203B SC813MFTQC-350CB 2U Chassis: SC213LT-600LPB SC825TQ-R720LPB SC823TQ-653LPB 3U Chassis: SC833T-653B Mid/Mini Tower Chassis: SC732I-500B SC731i-300B 4U / Tower Chassis: SC842TQ-665B SC842i-500B Important Chassis Notes To support the new generation Intel® Xeon® processor-based motherboards, Revision M chassis is recommended. Please talk to your sales representative for details. SuperServer(s) with X11SSL-F Model(s) SYS-5039D-I SYS-5019S-L Expansion Slots PCI-Express 1 PCI-E 3.0 x8 (in x16) slot 1 PCI-E 3.0 x8 slot 1 PCI-E 3.0 x4 (in x8) slot System BIOS BIOS Type 128Mb SPI Flash EEPROM with AMI BIOS BIOS Features Plug and Play (PnP) APM 1.2 DMI 2.3 PCI 2.3 ACPI 1.0 / 2.0 / 3.0 / 4.0 USB Keyboard support Hardware BIOS Virus protection SMBIOS 2.7.1 UEFI 2.3.1 RTC (Real Time Clock) Wakeup Management Software IPMI 2.0 with KVM support NMI Watch Dog SuperDoctor® 5 Power Configurations ACPI Power Management Keyboard Wakeup from Soft-Off CPU Fan auto-off in sleep mode Power-on mode for AC power recovery PC Health Monitoring Voltage Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages. FAN Total of 5 fan headers supporting up to 5 fans 5 fans with tachometer status monitoring Status monitor for speed control Status monitor for on/off control Low noise fan speed control Pulse Width Modulated (PWM) fan connectors Temperature Monitoring for CPU and chassis environment CPU thermal trip support I2C temperature sensing logic Thermal Monitor 2 (TM2) support PECI LED CPU / System Overheat LED Suspend static indicator LED UID/Remote UID Other Features Chassis intrusion detection Chassis intrusion header Chipkill support RoHS
