ASRock MB P4I65G (478,intel, DDR, VGA, AGP+PCI, 2xSATA, 2x100, 5.1, LAN, mATX)

P4i65G

Socket 478 for Intel® Pentium® 4 / Celeron® D (Prescott, Northwood, Willamette) processors
Intel® 865G Chipset
FSB800/533/400MHz processor, and H-T Technology
Supports Dual Channel DDR400 (DDR x 2 DIMMs)
Untied Overclocking : During Overclocking, FSB enjoys better margin due to fixed AGP/ PCI Buses
1 x AGP 8X slot
Supports Integrated Intel® Extreme Graphics 2 and DirectX 8.0
Hybrid Booster - Safe Overclocking Technology
2 ports of SATA 1.5Gb/s, 2 ATA100 IDE ports
5.1 Channel Audio, 10/100 Ethernet LAN
ASRock I/O Plus: 6 ready-to-use USB 2.0 ports

This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.



CPU

- Socket 478 for Intel® Pentium® 4 / Celeron® D (Prescott, Northwood, Willamette) processors
- FSB 800/533/400MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology


Chipset

- Northbridge: Intel® 865G
- Southbridge: Intel® ICH5


Memory

- Dual Channel DDR memory technology
- 2 x DDR DIMM slots
- Supports DDR400/333/266 non-ECC, un-buffered memory
- Max. capacity of system memory: 2GB


BIOS

- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports Jumperfree
- SMBIOS 2.3.1 Support


Graphics

- Integrated Intel® Extreme Graphics 2
- DirectX 8.0
- Max. shared memory 96MB


Audio

- Cmedia 9761A 5.1 channel audio CODEC


LAN

- Realtek PCI LAN 8101L
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
- Supports PXE


Slots

- 3 x PCI slots
- 1 x AGP 8X slot
- 1 x AMR slot


Connector

- 2 x SATA 1.5 Gb/s connectors (No Support for "RAID" and Hot Plug functions )
- 2 x ATA100 IDE connectors (support 4 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM header
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- AUX in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports; 2 of them are shared with USB4_5)


Rear Panel I/O

ASRock I/O Plus
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA Port
- 1 x Parallel Port (ECP/EPP support)
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port
- Audio Jack: Line in / Front Speaker / Microphone


Unique Feature

Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)


Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version)


Accessories

- Quick Installation Guide, I/O Shield
- Floppy/ATA 100 Cables
- 1 x SATA Data Cable
- 1 x SATA 1 to 1 Power Cable
- 1 x COM Port Bracket
- 1 x AMR card


Hardware Monitor

- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Overheat Shutdown to Protect CPU Life
- CPU Fan Tachometer
- Chassis Fan Tachometer
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore


Form Factor

- Micro ATX Form Factor: 9.6-in x 7.8-in, 24.4 cm x 19.8 cm


OS

- Microsoft® Windows® 98SE / ME / 2000 / XP compliant


Certifications

- FCC, CE, WHQL



The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
