ViewsonicIFP7552-1A 75" dotykový 4K 7H/350cd//8ms/3xHDMI/VGA/DP/RS232/OPS/RJ45/7xUSB/USB-C/Repro 2x15/VESA/Android 9

IFP7552
ViewBoard® 75" 4K Interactive Display
USB-C for plug-and-play connectivity via a single cable
Angular design with easy access shortcut keys for seamless usability
Dual-pen, 33-point touch with naturally smooth writing experience
Industry-leading audio and advanced eye-care technology
Centralized remote management system via myViewBoard Manager

OVERVIEW
The ViewBoard® 52 Series is a 4K Ultra HD interactive whiteboard equipped with user-centric design features and best-in-class collaboration tools for today’s lessons made easy. With a single-cable solution for instant, worry-free connectivity and a unique angular design for easy access to shortcut keys and I/O ports, teachers can seamlessly connect and control for uninterrupted, flowing classes. Dual-pen capability, 33-point touch, Ultra Fine Touch and palm awareness technology combine for a naturally smooth writing experience and endless opportunities for student collaboration, supported by 2X15W front-facing speakers and a 15W subwoofer for amplified student engagement. In another industry-first feature of the display, teachers facilitating distance or hybrid learning from their personal device can easily access the 8-mic array and any connected visualizer to select the most appropriate camera and mic source. Complete with a browser-based remote management system, the ViewBoard 52 Series delivers a market-leading interactive whiteboard solution for teachers, students, and IT managers.

SPECIFICATIONS
Display
Panel Size: 75"
Panel Type: TFT LCD Module with DLED Backlight.
Display Area (mm): 1649.644(H) x 927.936(V)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors (10bit)
Brightness: 400 nits (typ.)
Contrast Ratio: 1200:1 Typ. , 5000:1 Max.(DCR enable)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 Hours (Typ.)
Surface Treatment: Hardness: 7H (9H pencil), Anti-flare coating
Platform
Processor: ARM Cortex A73*4
RAM: 4GB (IFP7552-1A)8GB (IFP7552-1B)
Storage: 32GB (IFP7552-1A)64GB (IFP7552-1B)
Touch
Type/ Tech: UFT (Ultra Fine Touch) Technology
Touch Resolution: 32767 x 32767
Touch Point: Windows: 33 points touchAndroid: 20 points touch
INPUT
HDMI: x2 (3840x2160@60Hz, HDCP2.2, CEC, Front x1, Side x1)x1 (3840x2160@60Hz, HDCP2.2, CEC, ARC, Side x 1)
RGB / VGA: x1 (1920x1080 @60Hz)
DisplayPort: x1 (3840x2160 @60Hz)
Audio: x1 (PC audio in)
RS232: x1
OPS: module slot x 1
WiFi: module slot x 1
OUTPUT
HDMI: x1 (on demand)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)
LAN
RJ45: x1
USB
Type A: USB 2.0 x1(Side x1)USB 3.0 x4 (Front x2, Side x2, SmartPort™ USB)
Type B: x2, for touch
Type C: x1 (USB3.0, DP1.2 Alt Mode, 100M Ethernet, 60W PD)
SPEAKERS
15W x 2 + 15W x 1 subwoofer
MICROPHONE
built-in 8-array microphone
Top Camera Plate
Yes
Embedded OS
Android 9
Bundle Software
Basic Annotation Software: myViewBoard WhiteBoard for Android
Pro Annotation Software: myViewBoard WhiteBoard for Windows (embedded in VPC)
Wireless Presentation: ViewBoard Cast & myViewBoard Display
Special Features
All-in-one USB port (combine Windows/Android USB port; no need to distinguish them anymore): USB 3.0 x 4
Simple LAN sharing between IFP and slot-in device: 10/100/1000M for Android and PC
Light Sensor: Yes
Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 227W (Typ.) < 0.5 W ("Off")
ERGONOMICS
Wall Mount (VESA® ): 800 x 400
OPERATING CONDITIONS
Temperature (o C): 0°C to 40°C
Humidity: 20% ~ 80% RH Non-Condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 1720.1 (W) x 1069.6 (H) x 118.4 (D) mm 67.72 (W) x 42.11 (H) x 4.66 (D) inch
Packaging (inch / mm): 1880 (W) x 1160 (H) x 280 (D) mm74.02 (W) x 45.67 (H) x 11.02 (D) inch
WEIGHT
Net (lb / kg): 125.22 lb / 56.8 kg
Gross (lb / kg): 158.95 lb / 72.1 kg
REGULATIONS
cTUVus, FCC, EPEAT, Mexico coc, Mexico Energy, RoHS, Energy Star 8, CEC, EMC/CE, CB, RoHS & DOC, REACH, WEEE, ErP. EEI, RCM, BIS, PSE, VCCI, CCC, CECP, BSMI
PACKAGE CONTENTS
1. Power cable(3 meters) 2. Remote control 3. USB Type-C cable (1.5 meters) 4. USB Touch cable (3 meters, USB2.0) 5. Touch pen x 2 6. Quick Start Guide + Compliance statement 7. RS232 adapter 8. Clamp x 5 9. Camera Plate 10. Screw x 8 (camera 2+2, wall mount 4) 11. HDMI cable (3 meters) 12. Eraser 13. 13. AAA Battery x 2
Compatible Slot-in PC
VPC12 & VPC25/27-O & VPC25/27-O-B series
