SUPERMICRO MB 1xLGA2066, iC422, 8x DDR4 ECC, 8xSATA3, M.2, 6x PCI-E 3.0, 2x LAN,IPMI
Obrázky mají pouze informativní charakter a mohou se lišit od skutečnosti.

Recenze spokojených zákazníků:

Obchod mohu doporučit, byli ochotni doplnit i specifikace, které nemají na stránkách. Doporučuji se zeptat na možnost prodloužení záruky, není u všech produktů uvedena.

Ověřený zákazník

Supermicro MB 1xLGA2066, iC422, 8x DDR4 ECC, 8xSATA3, M.2, 6x PCI-E 3.0, 2x LAN,IPMI

Key Features   Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors, Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP Intel® C422 Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots 3 PCI-E 3.0 x8, 1 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 (in x16 slot),…
Kategorie: Základní desky Supermicro
Kód: 2859838PN: MBD-X11SRL-F-OVýrobce: SupermicroZáruka: 2 roky
Výrobek pochází z oficiální české distribuce.Více informací…
Aktuálně není v nabídce

Popis produktu

Key Features
  1.
  2. Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors, Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP
  3. Intel® C422
  4. Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
  5. 3 PCI-E 3.0 x8,
    1 PCI-E 3.0 x16,
    1 PCI-E 3.0 x8 (in x16 slot),
    1 PCI-E 3.0 x4 (in x8 slot)
    M.2 Interface: 1 PCI-E 3.0 x4
    M.2 Form Factor: 2280/22110
    M.2 Key: M-Key
    Double Height Connector
  6. Dual LAN with Intel® i210 Gigabit Ethernet Controller
  7. Intel® C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

Links & Resources

Specifications
Product SKUs
MBD-X11SRL-F
  • X11SRL-F

Physical Stats
Form Factor
  • ATX
Dimensions
  • 12" x 9.6" (30.48cm x 24.38cm)

Processor/Cache
CPU
  • Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors
  • Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP
Cores / Cache
  • 18 cores, 36 threads
Note
  • W-2200 CPU is supported on the motherboards with BIOS 2.0 or newer upon receiving from Supermicro
Note
  • To support 165W W-2200 CPUs, BIOS 2.0 & VRM update by Supermicro are required

System Memory
Memory Capacity
  • Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
Memory Type
  • 2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM
DIMM Sizes
  • 4GB, 8GB, 16GB, 32GB, 64GB, 128GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors

On-Board Devices
Chipset
  • Intel® C422
SATA
  • Intel® C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
IPMI
  • ASPEED AST2500
Network Controllers
  • Dual LAN with Intel® i210 Gigabit Ethernet Controller
Graphics
  • Aspeed AST2500 BMC

Input / Output
SATA
  • 8 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
USB
  • 6 USB 2.0 ports (2 rear + 4 via headers)
  • 5 USB 3.2 Gen1 ports (2 rear + 2 via headers + 1 Type A)
Video Output
  • 1 VGA port
Serial Port / Header
  • 2 COM Ports (1 rear, 1 header)
TPM
  • TPM Header
Expansion Slots
PCI-E
  • 3 PCI-E 3.0 x8,
  • 1 PCI-E 3.0 x16,
  • 1 PCI-E 3.0 x8 (in x16 slot),
  • 1 PCI-E 3.0 x4 (in x8 slot)
M.2
  • M.2 Interface: 1 PCI-E 3.0 x4
  • Form Factor: 2280/22110
  • Key: M-Key
  • Double Height Connector

System BIOS
BIOS Type
  • AMI UEFI
BIOS Features
  • ACPI 6.2
  • SMBIOS 3.0 or later
  • UEFI 2.7

Management
Software
  • IPMI2.0, KVM with dedicated LAN, SUM, SuperDoctor® 5, Watchdog
Power Configurations
  • ACPI Power Management
  • CPU thermal trip support for processor protection
  • Power-on mode for AC power recovery

PC Health Monitoring
Voltage
  • +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, System temperature, VBAT
FAN
  • 7x 4-pin fan headers (up to 7 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control
Temperature
  • PECI, CPU thermal trip support, Thermal Control for 6 Fan Connectors
LED
  • CPU / System Overheat LED, UID/Remote UID, Suspend static indicator LED
Other Features
  • ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, RoHS, UID

Operating Environment
Operating Temperature Range
  • 0°C ~ 50°C (32°F ~ 122°F)
Non-Operating Temperature Range
  • -20°C ~ 60°C (-4°F ~ 140°F)
Operating Relative Humidity Range
  • 10% ~ 85% (non-condensing)
Non-Operating Relative Humidity Range
  • 10% ~ 95% (non-condensing)

Parts List
Parts List (Bulk Package)
Name Part Number Qty Description
Motherboard MBD-X11SRL-F 1 X11SRL-F Motherboard
I/O Cables CBL-0044L 2 57.5CM SATA FLAT S-S PBF
I/O Shield MCP-260-00042-0N 1 STD I/O Shield for X11SRL-F with EMI Gasket

Parts List (Retail Package)
Name Part Number Qty Description
Motherboard MBD-X11SRL-F 1 X11SRL-F Motherboard
QRG MNL-2176-QRG 1 Motherboard Quick Reference Guide
I/O Cables CBL-0044L 6 57.5 cm SATA FLAT S-S PBF
I/O Shield MCP-260-00042-0N 1 STD I/O Shield for X11SRL-F with EMI Gasket


Chassis (Optimized for

X11SRL-F

)
Embedded Compact 1U 2U 3U Mid/Mini-Tower             4U/Tower
SC825TQC-R740LPB
SC825TQC-600LPB
SCLA25TQC-R609LP
SCLA26E1C4-R609LP
 SC733TQ-668B
 SC842TQC-668B
SC743AC-668B
= Most optimized Chassis for SuperServer Configuration
Blue color = Compatible
Green color = Global SKU & Compatible
Red dot & green color = Optimized + Global SKU

Parametry

Integrovaný řadič SAS/SATANe
M.2 slot1
Maximální frekvence paměti [MHz]2666
PCI Express x163
PCI Express x42
Počet paměťových slotů8
Podpora ECCANO
Typ pamětiDDR4
Integrovaná grafická kartaANO
Čipová sadaIntel C602 Chipset
Patice (CPU Socket)LGA 2066 socket
Počet CPU socketůSingle socket
Výrobce čipsetuIntel
FormátATX
HerníNE
UrčeníServery
