Supermicro MB 1xLGA2011 iC602 8x DDR3 ECC R,2xSATA3, 4xSATA2 2,1 PCI-E 3.0 (x16,x8),2xLAN,IPMI, WIO

Serverový konfigurátor

1. Single socket R (LGA 2011) supports Intel® Xeon® processor E5-2600/1600 and E5-2600/1600 v2 family† 2. Intel® C602 chipset 3. Up to 512GB ECC DDR3, up to 1866MHz; 8x DIMM sockets 4. Expansion slots: 2 PCI-E 3.0 x16 1 PCI-E 3.0 x8 (in x16) 5. Intel® i350 Dual port GbE LAN 6. SATA3 (6Gb/s) w/ RAID 0, 1, 5, 10 SATA2 (3Gb/s) w/ RAID 0, 1, 5, 10 7. Integrated IPMI 2.0 and KVM with Dedicated LAN 8. 8 USB 2.0 ports (4 rear + 4 via header) 9. DOM power connector support Physical Stats Form Factor Proprietary Dimensions 8.15" x 13.05", (20.7cm x 33.1cm) Processor/Cache CPU Single Socket R (LGA 2011) Intel® Xeon® processor E5-2600/1600 and E5-2600/1600 v2 family† (up to 12 cores and up to 135W) Note † BIOS version 3.0 or above is required System Memory Memory Capacity 8x 240-pin DDR3 DIMM sockets Up to 512GB DDR3 ECC LRDIMM Up to 256GB DDR3 ECC RDIMM Up to 64GB DDR3 ECC/non-ECC UDIMM Memory Type 1866/1600/1333/1066MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs DIMM Sizes 32GB, 16GB, 8GB, 4GB, 2GB, 1GB, 64GB LRDIMM Memory Voltage 1.5 V, 1.35 V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset Intel C602 chipset SATA SATA 2.0 3Gb/s with RAID 0, 1, 5, 10 SATA 3.0 6Gb/s with RAID 0, 1, 5, 10 IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450RA0BX Network Controllers Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output Video Matrox G200eW 16MB DDR2 graphics controllers Input / Output SATA 2 SATA 3.0 ports (6Gb/s) 4 SATA 2.0 ports (3Gb/s) SCU 4 SATA ports (3Gb/s) via SCU LAN 2 RJ45 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port USB 8 USB 2.0 ports total (4 rear + 4 via header) Video 1 VGA port Serial Port / Header 1 serial port DOM 1 DOM (Disk on Module) power connector TPM 1 TPM 1.2 20-pin Header Expansion Slots PCI-Express 2 (x16) PCI-E 3.0 slots 1 (x8) PCI-E 3.0 (in x16) slot System BIOS BIOS Type 64Mb SPI Flash EEPROM with AMI BIOS BIOS Features Plug and Play (PnP) APM 1.2 DMI 2.3 PCI 2.3 ACPI 1.0 / 2.0 / 3.0 / 4.0 USB Keyboard support Hardware BIOS Virus protection SMBIOS 2.7.1 UEFI 2.3.1 RTC (Real Time Clock) Wakeup Management Software IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support SuperDoctor® III Watch Dog NMI Power Configurations ACPI / APM Power Management Keyboard Wakeup from Soft-Off CPU Fan auto-off in sleep mode Power-on mode for AC power recovery PC Health Monitoring Voltage Monitors for CPU Cores, +3.3V, +5V, ±12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages. FAN Total of five 4-pin fan headers supporting up to 5 fans 5 fans w/ tachometer status monitoring Status monitor for speed control Status monitor for on/off control Low noise fan speed control Pulse Width Modulated (PWM) fan connectors Temperature Monitoring for CPU and chassis environment CPU thermal trip support I2C temperature sensing logic Thermal Monitor 2 (TM2) support PECI LED CPU / System Overheat LED Suspend static indicator LED UID/Remote UID Other Features Chassis intrusion detection Chassis intrusion header Chipkill support RoHS, Halogen Free
