MSI Modern 15 B7M-233CZ/Ryzen 7 7730U/16GB/1TB SSD/15.6" FHD IPS/Win11

MSI Modern 15 B7M-233CZ/Ryzen 7 7730U/16GB/1TB SSD/15.6" FHD IPS/Win11

MKT Spec Modern 15 B7M-233CZ
System/Barebone System
Chassis Color
Color ID1(CB)/Classic_Black-Black-Classic_Black-Black
Color_Website Classic Black
Chassis Material
A Side Plastic
B Side Plastic
C Side Plastic
D Side Plastic
Display
Screen Size 15.6
Resolution IPS-Level FHD
Pixel 1920x1080
LCD Features ANTI-GLARE
Screen Touch Non-touch
Frame Rate 60Hz
Response Time Tr+Tf 25ms
Color Range 45%
Screen Size_Website 15.6"
Pixel_Website FHD(1920x1080)
Frame Rate_Website N/A
Color Range_Website N/A
Display Type_Website IPS-Level
HDR Value N/A
Touch Feature_Website NA
CPU
CPU Type 8 CORE
CPU Core Name Ryzen 7
CPU Socket BGA-1140pin
CPU Number Ryzen 7 7730U
CPU Clock 2.0GHz
CPU Cores 8
CPU Core Name_Website AMD
CPU Number_Website Ryzen™ 7 7730U Processor
CPU Specification_Website 8 cores, Max Boost Clock 4.5 GHz
Chipset
Chipsets N/A
Chipset SoC_Website Integrated SoC
Discrete Graphics
GPU1 Vendor N/A
GPU1 MKT Name N/A
GPU1 Number UMA
GPU1 MKT Name_Website N/A
GPU1 Boost Clock_Website N/A
GPU1 Remark_Website N/A
CPU and GPU Combined Power
Combined Power_Website N/A
OverBoost Ultra Remark_Website N/A
Scenario Remark_Website N/A
Cooling
Thermal Cooler Boost
Fan 1
Pipe 2
Video Memory
GPU1 VRAM Size N/A
GPU1 VRAM Type N/A
Integrated Graphics
GPU1 Graphics_Website N/A
Memory
Memory Size 16GB
Memory Type DDR4-3200 onboard
Memory Speed N/A
Memory Remark_Website N/A
Memory Slot and Max Capacity
Memory Slot NA
Memory Max Capacity_Website Max 16GB
Storage
SSD Interface PCIe GEN4x4 w/o DRAM NVMe
SSD Form Factor M.2-2280 M-Key
SSD Size 1TB*1
HDD1 Interface N/A
HDD1 Form Factor N/A
HDD size N/A
HDD1 RPM N/A
ODD Type N/A
Multi Bay N/A
SSD Gen_Website NVMe SSD PCIe Gen4
2.5" HDD_Website N/A
SSD Remark N/A
Storage Slot
SSD (NVMe PCIe Gen)_Website 1x M.2 SSD slot (NVMe PCIe Gen3)
Communications
Accessory Lan_Website NA
LAN
LAN_Website N/A
LAN N/A
Wi-Fi/ Bluetooth
WLAN/BT_Website AMD RZ608 Wi-Fi 6E, Bluetooth v5.2
WLAN Version Wi-Fi 6E+BT
WLAN/BT AMD/AMD RZ608
I/O Ports
Audio Line In N/A
Audio Line Out N/A
Digital out SPDIF N/A
RJ45 NA
USB Ports
Type-C (USB3.1 Gen2/ DP/ Thunderbolt™3 optional) NA
Type-C (USB3.2 Gen2/ DP/ Thunderbolt™3) NA
Type-C (USB3.2 Gen1/ DP/ Thunderbolt™3) NA
Type-C (USB3.2 Gen2/ DP/ Thunderbolt™3) with PD charging NA
Type-C (USB3.2 Gen2/ DP) NA
Type-C (USB/ DP/ Thunderbolt™ 4) with PD charging NA
Type-C (USB/ DP/ Thunderbolt™ 4) NA
Type-C (USB/ DP/ Thunderbolt™) with PD charging N/A
Type-C (USB3.2 Gen2 / DP) with PD charging N/A
Type-C (USB3.1 Gen1/ DP) NA
Type-C (USB3.2 Gen1/ DP) NA
Type-C USB3.1 Gen2 NA
Type-C USB3.2 Gen2 NA
Type-C USB3.2 Gen2 with PD charging 1x
Type-C USB3.1 Gen1 NA
Type-C USB3.2 Gen1 NA
Type-A USB3.1 Gen1 NA
Type-A USB3.2 Gen1 NA
Type-A USB3.1 Gen1/ QC3.0 NA
Type-A USB3.2 Gen1/ QC3.0 NA
Type-A USB3.1 Gen2 NA
Type-A USB3.2 Gen2 1x
Type-C USB3.2 Gen2x2 NA
Type-A USB3.1 NA
Type-C USB3.0 N/A
Type-A USB3.0 NA
Type-A USB2.0 2x
USB3.2 Gen 2 Type-C(connect to computer) NA
Card Reader
CardReader 1x Micro SD
Video Ports
VGA Out NA
HDMI™ 1x HDMI™ 2.1 (4K @ 60Hz)
DisplayPort NA
Mini Display Port NA
Keyboard
Keyboard Types_Website Single Backlit Keyboard (White)
Keyboard Keys 99KEYS
Keyboard Backlit Y
Keyboard Numeric N/A
Keyboard Color BLACK
Keyboard Language CS Wleft Nokr
WebCam
WebCam HD type (30fps@720p)
Audio Port
Audio Jack_Website 1x Mic-in/Headphone-out Combo Jack
Audio
Audio Speaker 2x 2W
Audio Woofer NA
Audio Solution_Website Hi-Res Audio Ready
AC Adapter
Adaptor Output 65W adapter
Adaptor 65W
Adaptor Input 90-264Vin
Battery
Battery Type 3CELLS/3S1P
Battery Cell_Website 3-Cell
Whrs 39.3 / 53.8
Operating Systems
OS MULTI-LANGUAGE(WIN 11 HOME PLUS OLC OA3)
OS Type W11MH
OS_Website Windows 11 Home (MSI recommends Windows 11 Pro for business.)
Dimension (WXDXH)
Dimension 359 x 241 x 19.9 mm
Dimension(Inches)_Website 14.13" x 9.49" x 0.78"
Weight (W/ Battery)
Weight 1.75 kg
Weight(lbs)_Website 3.86 lbs
Weight (Docking) N/A
Weight (lbs Docking)_Website N/A
Security
Security Type_Website Firmware Trusted Platform Module(fTPM) 2.0
Software
Software MSI Center Pro
Model Info
Series Name Business& Productivity
Segment Name Modern
Segment Name2 Modern15B
Segment Name3 Modern15 B7M
Barcode Info
EAN 4711377104272
