Launch Date |
13th January 2020 |
|||
|
Category |
SSD |
|||
|
Part Numbers / UPC Code |
SEDC1000BM8/240G |
740617303599 |
||
|
SEDC1000BM8/480G |
740617303612 |
|||
|
SEDC1000BM8/960G |
740617315349 |
|||
|
Country of Origin |
China |
|||
|
Dimension of Product |
80mm x 3.5mm x 22mm |
(L x W x H) |
||
|
Dimension of Packaging |
184.2mm x 9.1mm x 129.5mm |
(L x W x H) |
||
|
Unit Net Weight / Gross Weight |
8.5g / 41g |
|||
|
Dimension of Carton |
203.2mm x 135.9mm x 63.5mm |
(L x W x H) |
||
|
Carton Quantity / Weight |
10 / 481.3g |
|||
|
Warranty**** |
Limited 5-year warranty with free technical support |
|||
|
Specifications |
|
|
Form factor |
M.2 (2280) |
|
Interface |
PCIe NVMe Gen3 x4 |
|
Capacities* |
240GB, 480GB, 960GB |
|
NAND |
3D TLC |
|
Self-encrypting drive (SED) |
AES 256-bit encryption |
|
Sequential read/write |
240GB – 2,200MBs/290MBs 480GB – 3,200MBs/565MBs |
|
Steady-state 4k read/write** |
240GB – 111,000/12,000 IOPS 480GB – 205,000/20,000 IOPS |
|
Latency read (avg) |
161µs |
|
Latency write (avg) |
75µs |
|
Power loss protection (power caps) |
Yes |
|
SMART Health Monitoring and Telemetry |
SMART, Telemetry and other Enterprise Class Diagnostic capabilities |
|
Endurance*** |
240GB – 248TBW – (0.5 DWPD/5yrs) 480GB – 475TBW – (0.5 DWPD/5yrs) 960GB – 1095TBW – (0.6 DWPD/5yrs) |
|
Power consumption |
240GB - Idle: 1.82W Average read: 1.71W Average write: 3.16W Max read: 1.81W Max write: 3.56W 480GB - Idle: 1.90W Average read: 1.74W Average write: 4.88W Max read: 1.81W Max write: 5.47W 960GB - Idle: 1.29W Average Read: 1.67W Average Write: 4.25W Max Read: 1.78W Max Write: 5.73W |
|
Storage temperature |
-40°C ~ 85°C |
|
Operating temperature |
0°C ~ 70°C |
|
Vibration operating |
2.17G peak (7-800Hz) |
|
Vibration non-operating |
20G peak (10-2,000Hz) |
|
MTBF |
2 million hours |
