| Chipset | Baytrail-D |
| CPU | Intel® Celeron J1800(2.41 GHz) Dual-Core Processor |
| MEMORY | Support Dual Channel DDR3/DDR3L 1333 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory |
| INTEGRATED VIDEO | Intel HD Graphics Supports DX11 Supports HDCP |
| STORAGE | 2 x SATA II Connector |
| LAN | Realtek RTL8111G - 10/100/1000Mb/s Controller |
| AUDIO CODEC | Realtek ALC662 6-Channel HD Audio |
| USB | 1 x USB 3.0 Port 2 x USB 2.0 Port 2 x USB 2.0 Header |
| EXPANSION SLOT | 1 x PCI-E 2.0 x16 Slot(x1 speed) 2 x PCI-E 2.0 x1 Slot |
| REAR I/O | 1 x PS/2 Mouse 1 x PS/2 Keyboard 1 x USB 3.0 Port 2 x USB 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x LAN Port 3 x Audio Jacks |
| INTERNAL I/O | 2 x USB 2.0 Header 2 x SATA II Connector (3Gb/s ) 1 x Front Audio Header 1 x Front Panel Header 2 x System Fan Connector 1 x COM Port Header 1 x Printer Port Header |
| H/W MONITORING | CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring |
| DIMENSION | Micro ATX Form Factor Dimension: 22.6cm x 18.8cm ( W x L ) |
| OS SUPPORT | Supports Windows 7 / 8 / 8.1 / 10(x64) |
| BUNDLE SOFTWARE | BullGuard BIO-Remote2 Smart Speed LAN Intel Smart Connect Technology |
| ACCESSORIES | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
| FEATURES | Supports Solid capacitor BIOS-Flasher Supports Charger Booster |
| Caution!! The specification and pictures are subject to change without notice! | |
