Chipset | AMD A520 |
CPU SUPPORT | Socket AM4 support AMD Ryzen™ 3rd Gen (Matisse/
Renoir) and Ryzen™ 4th Gen (Vermeer/ Future)
processors Support for future AMD Ryzen processors with BIOS update * Please refer to www.biostar.com.tw for CPU support list. |
MEMORY | 4th Gen AMD Ryzen Processors (Vermeer/ Future
CPUs): Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133 3rd Gen AMD Ryzen Processors (Matisse CPUs): Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133 3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs): Supports Dual Channel DDR4 4933+(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory Each DIMM supports non-ECC and ECC Un-buffered 8/ 16/ 32 GB DDR4 module * Please refer to www.biostar.com.tw for Memory support list. |
INTEGRATED VIDEO | By CPU model Supports DX12 Supports HDCP |
STORAGE | -- Total supports 1x M.2 socket and 4 x SATA III (6Gb/s)
ports 4 x SATA III Connectors (6Gb/s) : Supports AHCI & RAID 0, 1, 10 1 x M.2 (M Key) Socket: Supports M.2 Type 2242/ 2260/ 2280 SSD module Supports PCIe 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA III (6.0Gb/s) SSD |
LAN | Realtek RTL8111H 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability |
AUDIO CODEC | ALC897 7.1 Channels, High Definition Audio, Hi-Fi (Front) |
USB | 6 x USB 3.2 (Gen1) ports (4 on rear I/Os and 2 via internal
headers) 6 x USB 2.0 ports (2 on rear I/Os and 4 via internal headers) |
EXPANSION SLOT | 1 x PCIe 3.0 x16 Slot: Supports PCIe 3.0 x16 mode with AMD Ryzen™ processors. Supports PCIe 3.0 x16 mode AMD Ryzen™ with Radeon Vega Graphics processors. 2 x PCIe 3.0 x1 Slots * According to different CPUs will have different speeds. |
REAR I/O | 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x HDMI Port 1 x VGA Port 1 x LAN port 4 x USB 3.2 (Gen1) Ports 2 x USB 2.0 Ports 3 x Audio Jack |
INTERNAL I/O | 4 x SATA III (6.0Gb/s) Connectors 2 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Internal Stereo Speaker Header 1 x Clear CMOS Header 1 x COM Port Header 1 x TPM Header |
H/W MONITORING | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring |
DIMENSION | Micro ATX Form Factor Dimension: 20.8cm x 24.4cm ( W x L ) |
OS SUPPORT | Supports Windows 10(64bit) ?Biostar reserves the right to add or remove support for any OS with or without notice |
BUNDLE SOFTWARE | BullGuard |
ACCESSORIES | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
FEATURES | Supports 100% Solid capacitor BIOS-Flasher A.I FAN PCIe M.2 32Gb/s |
Caution!! The specification and pictures are subject to change without notice! |
