Specifications
Physical Status
Form Factor micro-ATX
Dimensions 9.6'' x 9.6'' (24.4 cm x24.4 cm)
Processor System
CPU AMD EPYC™ 7002 and 7001 series processor
Socket Single Socket SP3 (LGA4094)
Chipset System on chip
System Memory
Capacity 6 DIMM slots
Type DDR4 288-pin RDIMM, LRDIMM
Voltage 1.2V
Expansion Slot
PCIe 4.0 x 16 Slot 7: PCIe 4.0 x16
Slot 6: PCIe 4.0 x16
Slot 5: PCIe 4.0 x16
Slot 4: PCIe 4.0 x16
M.2 1 M-key (PCIe4.0 x4 or SATA 6Gb/s); support 2280 form
factor
1 M-key (PCIe4.0 x4 or SATA 6Gb/s); support 2260 form factor
[BTO]
Storage
SATA Controller 14 SATA 6Gb/s: 12 via mini-SAS HD, 2 via SATA
7-pin
Slimline for U.2 1 (PCIe4.0 x8), 2 (PCIe4.0 x8 or 8 SATA
6Gb/s)
Ethernet
Additional GbE Controller 1 Intel® X710-AT2: 2 RJ45 (10
GbE)
2 Intel® i210: 2 RJ45 (1 GbE)
Management
BMC Controller ASPEED AST2500
IPMI Dedicated GLAN 1 x Realtek RTL8211E for dedicated
management GLAN
Graphics
Controller ASPEED AST2500
Rear Panel I/O
VGA Port 1 DB15
USB 3.2 Gen1 Port 2
Lan Port 2 RJ45 (10GbE), 2 RJ45 (1GbE)
Dedicate LAN 1 RJ45 (Dedicated IPMI)
UID Button/UID LED 1
Power connector in Front side
Power connector 1(4-pin) + 2 (8-pin) support 12V DC-IN, 1
(4-pin) for HDD power
Internal Connector
COM Header 1
Front Lan LED Connector LAN3/LAN4 LED header
Auxiliary Panel Header 1 (18-pin): chassis intrusion, system
fault LED, LAN1/LAN2 activity LED, locate, SMBus
TPM Header 1 (17-pin, LPC)
Thermal Sensor Header 2
IPMB Header 1
PMBus CONN 1
Fan Header 6 (4-pin)
NMI Header 1
System Panel 1 (9-pin): power switch, reset switch, system
power LED, HDD activity LED
Speaker Header 1
BMC_SMB Header 1
SGPIO Header 3
CPU HSBP 1
Clear CMOS 1 (contact pads)
Onboard LED
Standby PWR LED 5vsb 1
Fan Fail LED 6
System BIOS
BIOS Type 32MB AMI UEFI Legal BIOS
Hardware Monitor
Temperature CPU/Car side / MB_A/ MB_B / DDR temperature
sensing
Fan Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU
Temperature)
Fan Multi-Speed Control
Voltage Voltage Monitoring: Vsoc,Vcpu, VCCM, VPPM, 3v/5v/12v,
+BAT, 3VSB, 5VSB,
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
The specification is subject to change without notice in advance.
The brand and product names are trademarks of their respective
companies. Any configuration other than original product
specification is not guaranteed.
M.2 slot | 2 |
---|---|
Maximální frekvence paměti [MHz] | 3200 |
Počet paměťových slotů | 6 |
Podpora ECC | ANO |
Typ paměti | DDR4 |
Integrovaná grafická karta | ANO |
Čipová sada | System on Chip |
Patice (CPU Socket) | SP3 socket |
Počet CPU socketů | Single socket |
Výrobce čipsetu | AMD |
Formát | ATX |
Herní | NE |
Určení | Servery |
