CPU
- Supports AMD Socket AM5 Ryzen™ 8000/7000 Series Processors, Max.
TDP 65W
-
Cooler
- Supports AMD AM5/AM4 CPU Cooler (Max. Height ? 47mm)
-
Memory
- Supports 2 x SO-DIMM DDR5-6400+(OC)MHz memory, Max. 96GB
(non-ECC)
-
Chipset
- AMD X600
-
Graphics
- HDMI (4K@120Hz)
- DisplayPort 1.4 (4K@120Hz)
- D-Sub
-
Audio
- Realtek ALC269 Audio Codec
-
Storage
- 2 x SATA3 6Gb 2.5-inch 7mm/9.5mm Hard Drive
- 1 x Blazing M.2 Socket (M2_1), support type 2280 PCIe Gen5x4 (128
Gb/s) mode
*
- 1 x Hyper M.2 Socket (M2_2), supports type 2280 PCIe Gen4x4 (64
Gb/s) mode
*
*Supports NVMe SSD as boot
disks
-
RAID
- Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
-
LAN
- 2.5 Gigabit LAN (Dragon RTL8125BG)
-
WLAN
- 1 x M.2 Socket (Key E), supports type 2230 Wi-Fi/BT module
-
Front I/O
- 1 x MIC-In
- 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)
- 1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection)
- 1 x Head Phone with MIC Jack
-
Rear I/O
- 1 x DC-In Jack (Compatible with the 19V power adapter)
- 1 x D-Sub Port
- 1 x HDMI Port
- 1 x DisplayPort 1.4
- 2 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED
-
Connectors
- 1 x USB 2.0 Header
- 1 x Front Panel Header
- 2 x 4-Pin fan connectors (CPU, SYS)
- 1 x Internal Speaker Header (4-Pin)
- 1 x Chassis Intrusion Header (2-Pin)
- 1 x Audio Header (4-Pin)
-
Accessory
- 2 x SATA Data with Power Cable
- 1 x 120W/19V adapter
- 1 x Screws Pack
-
Dimension
- 155 x 155 x 80 mm (1.92L)
-
OS
- Microsoft® Windows® 10 64-bit /
11 64-bit
