Bezdrátový VDSL/ADSL modem a router AC1200
Rychlá WiFi – Zažijte vynikající bezdrátové dvoupásmové připojení
WiFi 867 Mb/s (5 GHz) + 300 M/s (2,4 GHz)
Lepší dosah – Dvě pevné všesměrové antény s technologií Beamforming
poskytují stabilní bezdrátové připojení a optimální pokrytí
Všestranná konektivita – Plně kompatibilní se standardy
VDSL2/ADSL2+/ADSL2/ADSL a také s 3G/4G internetovými službami po
optickém kabelu a standardním kabelu
Pokrytí celé domácnosti pomocí OneMeshTM – Spolupracuje s produkty
TP-Link OneMeshTM pro vytvoření flexibilní Mesh sítě
Technologie MU-MIMO – Současně přenáší data do více zařízení,
zkracuje čas čekání
Plné gigabitové porty - Využijte všech výhod širokopásmových
rychlostí až do 1 Gb/s.
Tether aplikace – TP-Link Tether poskytuje nejjednodušší způsob
přístupu a správy routeru na zařízeních iOS a Android
HARDWARE FEATURES
Ports 3× 10/100/1000Mbps RJ45 LAN Ports,
1× 10/100/1000Mbps RJ45 WAN/LAN Port,
1× RJ11 Port,
1× USB 2.0 Port
Button WPS Button, Wi-Fi On/Off Button, Reset Button
External Power Supply 12V/1A
IEEE Standards IEEE 802.3, IEEE 802.3u, 802.3ab
VDSL2 Standards ITU G.993.2, Up to 17a profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)
ADSL Standards Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
ITU-T G.994.1 (G.hs),
ADSL2 Standards ITU-T G.992.3 (G.DMT.bis)
ADSL2+ Standards ITU-T G.992.5
Dimensions ( W x D x H ) 8.5 × 4.9 × 1.2 in (215.6 × 124.6 × 31.6
mm)
Antenna Type 2× fixed Omini-Directional antennas
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency 2.4 GHz and 5 GHz
Signal Rate 867Mbps at 5 GHz, 300Mbps at 2.4 GHz
Wireless Functions Enable/Disable Wireless Radio, WMM, Wireless
Statistics
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
encryptions
Transmission Power <20dBm (2.4 GHz), <23dBm (5 GHz)
Wireless Schedule Support 2.4 GHz and 5 GHz Wireless Schedule
SOFTWARE FEATURES
Security NAT Firewall, SPI Firewall, Access Control, Service
Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP
and MAC Address Binding
Operating Modes VDSL/ADSL Modem Router, Wireless Router, 3G/4G
Router
Management Web-Based Configuration (HTTP / HTTPS ), Remote
management,
Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware
Upgrade, Diagnostic Tools, Free Online Firmware Update
DHCP Server, Client, DHCP Client List, Address Reservation, DHCP
Relay
Port Forwarding Virtual Server, Port Triggering, DMZ, ALG, UPnP
Dynamic DNS DynDns, NO-IP, TP-Link
VPN OpenVPN, PPTP VPN, IPSec VPN
Protocols Supports IPv4 and IPv6
ATM/PPP Protocols ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC
1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
Advanced Features Parental Controls, Network Address
Translation(NAT), Port Mapping
(Grouping), Static Routing, RIP v1/v2 (optional), DDNS, IGMP
V1/V2/V3
Guest Network 2.4GHz Guest Network, 5GHz Guest Network
OTHERS
Certification CE, RCM, RoHS
Package Contents AC1200 Wireless MU-MIMO VDSL/ADSL Modem Router
Archer VR400
External Splitter
RJ11 DSL Cable
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or
Windows 7, 8, 8.1, 10, macOS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or
other
Java-enabled browser
Subscription with an internet service provider (for internet
access)
