| Video Output | |
| Requires Expansion Slot Standard: | PCI Express 4.0 x16 |
| Video Chipset: | Nvidia GeForce RTX 4070 Super |
| GPU Core Name: | AD104-350 |
| GPU Core Speed: | 1980 MHz |
| GPU Core Speed Boost: | 2475 MHz |
| GPU Quantity: | 1 |
| Stream Processors Quantity: | 7168 |
| Texture Mapping Unit Quantity: | 224 |
| Render Output Units Quantity (ROP): | 80 |
| Tensor Core Quantity: | 224 |
| Ray-tracing Cores Quantity: | 56 |
| Maximum Resolution: | 7680x4320 |
| 2D/3D Features: |
Nvidia GPU Boost Nvidia G-Sync Nvidia ShadowPlay Nvidia Ansel Nvidia DLSS NVIDIA FreeStyle NVIDIA Game Ready NVIDIA Studio NVIDIA Ada Lovelace NVIDIA Encoder 4th Gen Tensor Cores 3rd Gen Ray Tracing Cores NVIDIA GeForce Experience NVIDIA Decoder |
| API Supports: |
DirectX 12.0 OpenGL 4.6 Vulkan 1.3 |
| Memory | |
| Video Memory Type: | Video Controller Memory |
| Memory Type: | GDDR6X SDRAM |
| Installed Video Memory Storage Capacity: | 12 GB |
| Video Memory Speed: | 21 Gbps |
| Memory Bus Bandwidth: | 192 bit |
| Memory Bandwidth: | 504 GB/s |
| Interface Provided | |
| HDMI Interface Quantity: | 1 |
| HDMI Interface Connector Type: | HDMI (Type A) |
| DisplayPort Interface Quantity: | 3 |
| System Requirements | |
| Requires Operating System: |
FreeBSD Linux Microsoft Windows 10 or Later |
| External Power: | 2 x 8 pin |
| PSU Output Power Required: | 650 W |
| Miscellaneous | |
| Cooling System Type: | VGA Cooler |
| Included Accessories: | Documentation |
| Dimensions & Weight Device | |
| Depth (mm): | 250 mm |
| Height (mm): | 42 mm |
| Width (mm): | 118 mm |
